Modular multichamber desiccant dryer

These desiccant dryers offer a wide application spectrum by her modular construction. The dry containers are able either directly on the move shaft of a processing machine or as shown as a central processing unit are pursued. Dry air producers with aerial achievements to 2000 m³ / h and container volumes to 6000 litres are available.

 Dry Air Producer TLE 3, TLE 6

The drying unit consists of the air producer TLE 3 or TLE 6 and a drying container. The drying container can be selected between 30 litres up to 200 litres. Thus an induviduelle adjustment is possible to the drying need.

                                                      picture: TLE 3 with 30 Liter tank

	TLE 3	TLE 6
Technical data
Capacity in Liter	30 bis 100	80 bis 200
Dimension H/W/D in mm	850x330x750	900x400x800
Weight in kg	45	60
Drying Capacity in kg/h	6 - 20	20 - 40
Power consumption in V / kW	230 / 2,8	400 / 5,6
Fan flow rate in m³/h*	30	60
Product information	TLE 3.pdf	TLE 6.pdf
